PERFORMANCE SPECIFICATIONS

• Frequency Response: -10 dB 35 Hz – 800 Hz

• Suggested Cross-Over: max 120 Hz

• Nominal Dispersion: Quasi-Omnidirectional

• Impedance (Nom/Min): 4 Ω / 3.4 Ω

• Watt AES (Continuous/Peak): 1200 W / 4800 W

• Maximum SPL Output *: 142.5 dB SPL

* calculated using +10 dB Crest Factor signal @ 1 m, Half space

PHYSICAL

• Component: 1 x 18” direct radiation woofer

• Connectors: 2 x NL4 Pins 1+/1-

• Cabinet Material: Baltic birch plywood

• Cabinet Finish: Black polyurea coating

• Grill: Epoxy powder coated

• Installation Points: 16 x M8 threaded points

• Pole Mount: 2 x M20 threaded points

• Height: 570 mm – 22 1/2”

• Width: 570 mm – 22 1/2”

• Depth: 750 mm – 29 1/2”

• Weight: 47 kg – 103.6 lb
