FEATURES

• Neutrik TRUE 1 Connector

• RGBA LEDs on board.

• Optional Wireless DMX available.

• New structure design for multiple angle rigging

• Auto-sensing frequency

• Fluid tank compartment for ease of transportation

• Huge output volume with high pigments LED colors

• Great fit for Stage purpose

• Generate fog at any orientation

SPECIFICATION

Input voltage:

• US model : AC 100-120V, 50/60Hz 13A
• EU model : AC 220-240V, 50/60Hz 6.5A

Rated power:

• 1516W
• Light Source:
• 22 x 3W LED (5Red, 6Green, 6Blue, 5Amber)

Warm-up time:

• 7 minutes (approx.)
• Fluid consumption:
• 200 ml/min

Fluid tank capacity:

• 2.4 Liters (0.63 gallon)

Compatible fluid:

• Antari FLC Super Light Fog Fluid

Ambient temp/ range:

• 0°C – 40°C (32°F – 104°F)

Output:

• 10 meters height

Control:

• Manual, Timer, DMX 512,
• Master / Slave, Wireless
• Wireless DMX (Optional)

DMX channels:

• 9 channels
• Connection:
• Neutrik TRUE 1 Connector (Power)
• XLR 3-pin and 5-pin (DMX)

Dimension:

• L:346 W:193 H:383 mm
• Weight: 14 kg
